What Is a Prefabricated Steel Structure Building?

A prefabricated steel structure building is a bolt-together steel frame system in which every column, rafter, purlin, and connection plate is precision-cut, drilled, and welded in our factory — then containerized and shipped to your site for rapid assembly.

Unlike traditional on-site steel fabrication (which is slow, weather-dependent, and expensive in most countries), our approach delivers:

· 30–50% faster construction compared to conventional steel erection

· Zero on-site welding — 100% bolted connections

· Lower total project cost through factory efficiency and reduced site labor

· Consistent quality — every component passes dimensional inspection before packing

· This is not a "steel kit." This is a fully engineered structure, designed to your local wind, snow, and seismic loads.

Case  | 420 m² Private Riding Arena, Moncton, New Brunswick

Project Location: Moncton, New Brunswick Building Type: Indoor Riding Arena Floor Area: 420 m² (14 m × 30 m) Eave Height: 4.5 m; Ridge Height: 6.5 m Delivery Schedule: 22 days for design + 30 days for production + 28 days for land transportation & installation

Project Background

The client is a private equestrian enthusiast and amateur coach with 6 horses, requiring an all-year indoor training facility. New Brunswick has long winters from November to April with alternating rain and snow, leaving outdoor riding areas usable for less than 5 months per year. The specified snow load is 3.0 kPa (Ss=2.5, Sr=0.5).

Technical Solution

• Portal frame structure with a clear span of 14 m and bay spacing of 5.0 m. Eaves raised to 4.5 m (minimum clearance for horse riding ≥ 3.6 m).
• Roof: 100 mm rock wool sandwich panels to prevent condensation dripping in winter which may spook horses.
• Wall: 75 mm rock wool sandwich panels. 20 mm thick rubber protective liners installed on interior wall base up to 1.8 m height to protect steel wall panels from horse kicks.
• Floor: Riding area paved with professional equestrian silica-fiber sand mixture, 120 mm thick, with drainage layer and geotextile underneath.
• Natural lighting: Continuous translucent FRP daylight bands along both eaves, accounting for approximately 20% of wall area.
• Ventilation: 4 silent variable-speed exhaust fans mounted at the ridge to avoid noise startling horses.
• Ancillary facilities: A 4 m × 6 m tack room and hay storage room partitioned at one end.

Project Highlights

Continuous FRP daylight bands at eaves deliver even natural daylight, eliminating the need for artificial lighting during daytime. The indoor temperature can stay above 0°C in winter relying solely on heat generated by horses plus rock wool insulation, with no auxiliary heating required. Client feedback: "I can ride every day this winter, just like in summer."

Why Our Clients Choose Us

       · "I went with you because the price was 30% under the local quote. What I got was better than the Australian-made shed I put up in 2019."

· — Farm Owner, Queensland, Australia

Get Your Project Started — 3 Simple Steps

· Step 1 — Send Your Requirements Share your building dimensions, location, and intended use. A rough sketch, satellite image, or reference photo helps — but even just "I need a 20m × 40m warehouse in Mombasa, Kenya" is enough to start.

· Step 2 — Receive Your Custom Proposal Within 2–3 working days, you'll receive a preliminary structural layout, a bill of materials with pricing, and a shipping estimate — all free of charge and with zero obligation.

· Step 3 — We Engineer, Fabricate, and Ship Once you approve the detailed shop drawings, fabrication begins. We'll keep you updated with progress photos and container tracking numbers until your steel arrives on site.
