Cattle Barn Steel Structure with H-Section Beams and Sandwich Panel Roof
Cattle Barn Farm Shed Steel Structure Steel Roof Frame Used Steel Structure Warehouse Workshop
Advantages of Steel Structure Cattle Barn / Farm Shed
1. High Strength & Durability
- Steel offers superior load-bearing capacity, withstanding harsh weather (strong winds, heavy snow, etc.).
- Anti-corrosion treatments (e.g., hot-dip galvanizing) extend lifespan, outperforming traditional wood structures.
2. Quick Installation & Cost-Effective
- Prefabricated components enable fast on-site assembly, reducing construction time by over 50% compared to concrete buildings.
- Lower labor and building costs, ideal for urgent farm expansions.
3. Customizable & Flexible Design
- Adjustable span, height, and layout to fit various livestock or storage needs.
- Custom doors, windows, and ventilation systems optimize lighting and airflow.
4. Low Maintenance
- Resistant to rot, pests, and mold, minimizing long-term upkeep expenses.
5. Eco-Friendly & Sustainable
- 100% recyclable material, reducing waste and supporting green farming practices.
6. Multi-Purpose Usage
- Suitable not only for cattle barns but also for warehouses, machinery storage, feed sheds, and more.
Common Applications
- Dairy/beef cattle farms
- Horse stables or sheep shelters
- Agricultural equipment & feed storage
- Temporary or permanent farm facilities
| 1. Main Steel Structure |
| 1 |
Column / Pillar/ Post |
Welded H steel section |
Q235B/Q355B |
Painting/Hot-dip galvanized |
| 2 |
Beam/ Roof truss |
Welded H steel section |
Q235B/Q355B |
Painting/Hot-dip galvanized |
| 2. Sub-steel Structure |
| 1 |
Wall/Roof purlin |
C/Z steel |
Q235B |
Galvanized |
| 2 |
Tie rod |
Ø89/114/158mm |
Q235B |
Painting/Hot-dip galvanized |
| 3 |
Flexible Bracing |
Ø16/18/20mm |
Q235B |
Painting/Hot-dip galvanized |
| 4 |
Sag rod (straight/inclined) |
Ø12 steel bar |
Q235B |
Galvanized |
| 5 |
Brace Rod |
Ø35*2.5mm |
Q235B |
Galvanized |
| 6 |
Knee-brace |
L50*4.0mm |
Q235B |
Galvanized |
| 3. Roof &Wall |
| 1 |
Roof /Wall panel |
Steel sheet/Metal sheet |
0.326~0.8mm corrugated steel sheet |
| Insulated sandwich panel |
EPS,Glass wool/Rock wool/PU insulation |
| 2 |
Roof/Wall trimmings |
Ridge roof panel |
0.4~0.5 mm steel sheet |
| Flashing |
0.4~0.5 mm steel sheet |
| Gable wall trimming |
0.4~0.5 mm steel sheet |
| Wall corner trimming |
0.4~0.5 mm steel sheet |
| 4. Window &Door |
| 1 |
Window |
PVC/Aluminum frame |
Single/double glazing (Fixed/sliding/swing) |
| 2 |
Door |
Roll up door /sliding door |
Automatic and manual method |
| 5. Accessories |
| 1 |
Bolts |
Anchor bolts,High strength bolts,Galvanized bolts,Turnbuckle,shear stud |
| 2 |
Gutter |
Steel sheet/galvanized/Stainless steel(304) |
| 3 |
Downpipe |
PVC 110/160 |
| 4 |
Roof Ventilator |
Ø600 (Galvanized) |
| 5 |
Floor Plate (Mezzanine) |
Galvanized floor decking / 18~20mm Cement board |
QUANZHOU RIDGE STEEL STRUCTURE
1. We design different types and sizes building according to customer's needs, large or small, wide span: single span or multiple spans, the max span is 36m without middle column.
2. We proposal with low cost and maintenance: unit price range from USD25/m2 to USD50/m2 according to customers request.
3. The steel structure building fast construction and easy installation: time saving and labor saving, all the items are factory-made,pre-cut,pre-welded, pre-drilled,pre-painted or HDG in advance for saving cost and time.
4. Reduced construction waste, long using lifespan: up to 50 years.
5. We are using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc software to design different buildings according to request of Clients. We service clients from design, produce, delivery and election.We can design factors with Max. Wind 280KM/H, Earthquake Class C and Roof Snow Load 200kg/SQM.
6. Nice appearance and , Earthquake Resistance, Sound Insulation, Heating Insulation treatment.
7. Others: environmental protection, stable structure, High quake-proof, water proof and fire proof, and energy conserving.
If you have the design drawing, we could make the budget according to your design.
If not, you could advise the following parameters so that we could make the design and quotation accordingly.
| 1. Location (where will be built? ) |
_____country,area |
| 2. Size: |
_____mm(L) * _____mm(W) * _____mm(H) |
| 3. Live load on roof |
_____kn/m2; |
| 4. Wind load (max. Wind speed) |
_____kn/m2;or ____km/h,or_____m/s |
| 5. Snow load (max. Snow height) |
_____kn/m2;or _____mm |
| 6. Anti-earthquake |
_____ level |
| 7. usage of the building: |
_____ |
| 8. Brickwall needed or not |
if yes,1.2m or 1.5m in height |
| 9. Thermal insulation |
Panel Type ___________Sandwich Material ___________Sandwich thickness ____ |
| 10. Door quantity & size |
_____ units,____(width)mm*____(height)mm |
| 11. Window quantity & size |
_____ units,____(width)mm*____(height)mm |
| 12. Crane needed or not |
If yes,_____units,max. Lifting weight____tons;Max. Lifting height ____m |
| 13. Others |
Skylight belt,ventilator and any other accessories if needed. |
